Raster Physics: The Science of the CRT Electron Gun and Scanline Depth
Why does 240p look better on a CRT? Explore the technical physics of the electron gun, the shadow mask, and the depth of the scanline archive.
At NOSTOS, we document the Physics of the Image. Before the era of “Fixed Pixels” (OLED/LCD), the screen was an analog field generated by a high-energy electron stream. The Scanline-often misunderstood as a “flaw”-is actually the architectural backbone of the retro gaming aesthetic.
1. The Electron Gun Logic
Inside the neck of your PVM or BVM are three electron guns (Red, Green, Blue).
- The Beam: These guns fire a stream of electrons that are directed by magnetic “Deflection Yokes.”
- The Raster: The beam sweeps across the screen from top to bottom, 60 times per second.
Why 240p is Special
Traditional TV (480i) interlaced two fields of 240 lines to create a smooth moving picture. Retro consoles (NES to PS1) used a “cheat” in the timing of the VBI signal to force the guns to always hit the same 240 lines. This created a stable, non-flickering image with distinct “gaps” representing the un-drawn lines.
2. Shadow Mask vs. Aperture Grille
The way these electrons hit the phosphors is determined by a physical metal mask.
- Shadow Mask (Standard TVs): A metal sheet with millions of tiny holes. It creates a soft, “round” pixel structure that is characteristic of consumer-grade CRTs.
- Aperture Grille (Sony Trinitron/PVM): A series of vertical wires. This allows more electrons to hit the screen, resulting in a much brighter image and the sharp, vertical scanlines that collectors crave.
Technical Visual Comparison
| Feature | Modern LCD (1080p/4K) | Archival CRT (240p) |
|---|---|---|
| Pixel Structure | Fixed Grid | Dynamic Raster |
| Motion Clarity | Subject to Sample-and-Hold Blur | Instantaneous Phosphor Decay |
| Integer Scaling | Binary Upscaling (Often Soft) | Native Signal Integrity |
| Visual Texture | Flat | Layered (Scanline Depth) |
